30W-100W Integrated Solar Street Light

Short Description:

1. Lithium battery

Rated voltage: 12.8vdc

2. controller

Rated voltage: 12VDC

Capacity: 20a

3. lamp material: profile aluminum + die cast aluminum

4. Rated voltage of LED module: 30v5

Specification and model of solar panel:

Rated voltage: 18V

Rated power: TBD


Product Detail

Product Tags

PRODUCT DESCRIPTION

30W-100W integrated solar street light is compared to the split solar street light. Simply put, it integrates the battery, controller, and LED light source into one lamp head, and then configures the battery board, lamp pole or cantilever arm.

Many people don't understand what scenarios 30W-100W are suitable for. Let's give an example. Take rural led solar street lights as an example. According to our experience, rural roads are generally narrow, and 10-30w is usually enough in terms of wattage. If The road is narrow and only used for lighting, 10w is enough, and it is enough to make different choices according to the width of the road and the usage.

During the day, even on cloudy days, this solar generator (solar panel) collects and stores the required energy, and automatically supplies power to the LED lights of the integrated solar street light at night to achieve night lighting. At the same time, the 30W-100W integrated solar street light has PIR Motion Sensor can realize the infrared induction control lamp working mode of intelligent human body at night, 100% bright when there are people, and automatically change to 1/3 brightness after a certain time delay when there is no one, intelligently saving more energy.

The installation method of 30W-100W integrated solar street light can be summarized as "fool installation", as long as you can screw the screws, it will be installed, eliminating the need for traditional split solar street lights to install battery board brackets, install lamp holders, make battery pits and other steps. Greatly save labor costs and construction costs.

INSTALLATION METHOD

PRODUCT DATA

Item ISL-TX-S 30W ISL-TX-S 60W
LED Lamp 12V 30W 4800lm 12V 60W 9600lm
Lithium Battery(LifePO4) 12.8V 24AH 12.8V 30AH
Controller Rated voltage: 12VDC    Capacity: 20A Rated voltage: 12VDC    Capacity: 20A
Lamps Material profile aluminum + die-cast aluminum profile aluminum + die-cast aluminum
Solar panel Specification model Rated Voltage:18v     Rated power: TBD Rated Voltage:18v     Rated power: TBD
Solar Panel(mono) 60W 80W
Mounting Height 5-7M 7-9M
Space Between Light 16-20M 20-25M
System Life Span > 7 years > 7 years
PIR Motion Sensor 5A 10A
Size 767*365*106mm 1147*480*43mm
Weight 11.4/14KG 18.75/21KG
Package Size 1100*555*200mm 1240*570*200mm
Item ISL-TX-S 80W ISL-TX-S 100W
LED Lamp 24V 80W 12800lm 24V 100W 16000lm
Lithium Battery(LifePO4) 25.6V 54AH 25.6V 54AH
Controller Rated voltage: 12VDC    Capacity: 20A Rated voltage: 12VDC    Capacity: 20A
Lamps Material profile aluminum + die-cast aluminum profile aluminum + die-cast aluminum
Solar panel Specification model Rated Voltage:18v     Rated power: TBD Rated Voltage:18v     Rated power: TBD
Solar panel (mono) 110W 120W
Mounting Height 8-10M 9-11M
Space Between Light 25-28M 28-32M
System Life Span > 7 years > 7 years
PIR Motion Sensor 10A 10A
Size 1345*550*43mm 1469*550*45mm
Weight 23.5/26KG 30/33KG
Package Size 1435*640*200mm 1600*670*200mm

PRODUCT FEATURES

1. Designed by a professional industrial design team, it integrates solar panels, light sources, controllers, and batteries.

2. The design appearance is high-end and atmospheric. The whole lamp is formed by high-pressure cast aluminum, which is impact-resistant and high-temperature resistant. The surface adopts anodic oxidation process and has super corrosion resistance.

3. Intelligent power adjustment, automatically judge the weather, and reasonably plan the discharge law.

4. The whole lamp is super humanized design, easy to disassemble, easy to install, easy to transport.

PRODUCT ADVANTAGES

1. Easy to install, no need to pull wires.

2. Economical, save money and electricity.

3. Intelligent control, safe and stable.

PRODUCT DISPLAY

All-In-One-LED-Solar-Street-Light-1-1-new
2
通用1100
一体化控制器1240
电池1240-1
All-In-One-LED-Solar-Street-Light-5
All-In-One-LED-Solar-Street-Light-6
All-In-One-LED-Solar-Street-Light-7
